“Panel Bed” DIY Murphy Bed Frame Kit
Saves Loads of Space with an Easy-to-Lift Murphy Bed Cabinet You Build
**PLEASE NOTE: THIS KIT HAS A NEW DRILLING PATTERN, AS OF 10/1/21. PLEASE DRILL ONLY ACCORDING TO THE INSTRUCTIONS INCLUDED WITH YOUR KIT, NOT ANY PREVIOUSLY DOWNLOADED INSTRUCTIONS**
- Easy to Lift
- You Supply the Wood for the Cabinetry
- Comes in Twin, Full, Queen, and King Bed Sizes
- Durable Steel Frame with a Lifetime Warranty
- Spring Lift Mechanism Mounts to Cabinet Sides
- Vertical or Horizontal Mount Available
We Pay for Shipping! (Ships within one week)
Now Available with Murphy Bed Cabinet Hardware Kit!
Do It Yourself Panel Bed: A Murphy Bed Where the Doors Become the Bottom of the Bed
The Panel Bed Frame Kit allows you to build a Murphy Bed that has no doors to open, but instead has a face panel that folds down, becoming the bottom of the bed.
If you'd like us to manufacture all of the necessary cabinetry parts too, click here to look at our Panel Bed Cabinets.
Our Superior Panel Bed Frame Kit includes what you need to get started building your own Panel Bed System:
- Build Your Cabinet: Following our included instructions, your Superior Panel Bed / Alpha Frame Kit mounts to your cabinet made of 3/4" thick material, which mounts onto your wall, at the top of the cabinet. Note: no cabinetry or wood parts are included in this kit. For a bed-in-a-cabinet system, click here.
- Easy Lift and Lower: One pair of steel Spring-Balance-Lift Mechanisms (SBLMs), which secure to the sides of your cabinet, to raise and lower the panel bed
- Spring Loaded: 18 springs, to allow for various weight mattresses and face panels
- Strength and Support: Superior Steel Bed Frame, powder-coated to give a durable Black textured finish, with three steel stiffeners, holds up to 600 pounds (evenly distributed between two people & includes the weight of the mattress)
- Sturdy Feet: One pair of high-strength tubular 13" legs with a leg-connector bar for stability
- Bring Your Mattress: The Superior Panel Bed Frame Kit System works with any mattress up to 11 inches in thickness (Mattress not included)
- Vertical or Horizontal Mount: Mount your Panel Bed horizontally, with the optional horizontal leg rod
- In stock item: All of our Frame and DIY kits ships free from our warehouse in St Augustine, FL, within five business days, via FedEx ground (which takes 1-5 business days)
- Lifetime Warranty: Murphy Bed Depot has the best warranty money can buy on all of our Murphy Bed mechanisms and frames: A Lifetime Warranty! If you need any parts replaced because of manufacturer defect, we will ship you a replacement part quickly, at our cost.
No Cabinetry or Wood Parts are Included in this Kit
Do-it-yourself (DIY): All Murphy Bed Depot Frame and DIY kits come with all the hardware you need for the frame itself, making your assembly very do-able with some basic hand tools.
We Care About Your Safety: We've designed, tested, re-designed, and re-proven our products to make them as safe as possible for you and your guests to use.
Contact us at office@murphybeddepot.com or call toll free 1-866-844-9255 for further details.
Dimensions
Dimensions of the Panel Bed on a Cabinet System:
(using our included instructions):
Vertical Mount With 13" (Standard) Legs:
TWIN/SINGLE: 44.5" w x 83.25" h (XL is 88.25" h) x 16" d (Projection into room when down: 84.5" (XL is 89.5"))FULL/DOUBLE: 59.5" w x 83.25" h x 16" d (Projection into room when down: 84.5")
QUEEN: 65.5" w x 88.25" h 16" d (Projection into room when down: 89.5")
KING: 81.5" w x 88.25" h x 16" d (Projection into room when down: 89.5")
Horizontal Mount
(be sure to add the horizontal leg rod):
TWIN/SINGLE: 80" w (XL is 85" w) x 50" h x 16" d (Projection into room when down: 50")
FULL/DOUBLE: 80" w x 65" h x 16" d (Projection into room when down: 65")
QUEEN: 85" w x 71" h 16" d (Projection into room when down: 71")
KING n/a
Instructions

Assembly Instructions
Panel Bed Frame Kit
What is Included and What is Required
To build your own Panel Bed Cabinet System, you'll need:
- One Murphy Bed Depot Superior Panel Bed Frame Kit (ships in two boxes), known elsewhere as the "Alpha Bed - Steel Bed Frame System"
-
Our included instructions and cabinet cut list.
- Our Panel Bed Video Instructions
- Proper tools
- All wood parts
- All angle brackets and screws and hardware to build your own system (or purchase the Hardware Kit)
THE FRAME | SBF - STEEL BED FRAME
Our Panel Bed system is a lightweight, universal, structural steel bed frame with double overlap steel stiffeners. The design is complete with our fold-away leg system and is designed to exceed the strength of wood or aluminum as well as residential and commercial specifications. Our Panel Bed frames are made for use with Single, Double, Queen, or King size beds and the versatility of the design gives the user the option to mount the frame in the vertical or horizontal mode.
THE MECHANISM | SBLM - SPRING BALANCE LIFT MECHANISM
All sizes of the Panel Bed system include our heavy-duty, universal, easy-operation lift mechanisms. Designed for everyday use, this mechanism allows for varying spring combinations in order to balance all bed sizes Single through King, and creates easy fingertip operation.
Reviews
- Reviews
- Questions
- instructions
- parts
- cabinet
- hardware
- springs
- murphy bed
- assembly
- quality
- company
- design

We love our Horizonal Murphy bed
We purchased the Horizontal Panel Bed Frame Kit from Murphy Bed Depot. We then purchased Burch Plywood 3/4 in. from Home Depot. The assembly instructions were very well written and hardware cards well organized. It took 2 of us a few days to complete the bed frame, going at a slow pace. Our only hiccup was that we initially used 6 springs on each side and had to take it apart to reduce to 4 springs; was relatively easy to backtrack. We love it!!

Amazing Murphy Bed Kit
I spent a lot of time looking for a Murphy bed kit and finally settled on this one. Boy and I glad I did! The instructions were VERY thorough and worked perfectly. This bed is so solid and the mechanism is very easy to operate. So much so I haven’t had a single person say it’s cumbersome. Thank you for an awesome kit!

Excellent Product
The panel bed kit was a breeze to assemble. Had a little trouble with the spring installation but with a little customer service explanation that all springs are not the same so installation may very on which ones came with the kit. The cutting instructions and other installation instructions were right on.

Well designed, clear instructions, accurate cut list
The kit arrived in totality and all parts were included. We purchased the hardware kit as well which was worth the $30 or so extra. The cut list was accurate. The instructions were a little unclear at times however it was easy to figure it out once we could see how the parts functioned. The included tips regarding the spring installation were very helpful. Once the components were finished we were able to put the unit together and install it in one day. It functions very smoothly and it looks terrific! The only thing we added was a strong back on the back of the head board as it had a bit of give on the lower part that does not contact the wall. Other than that we are extremely happy with the product. We were able to make a quality murphy bed for less than a third the cost of buying the same thing. If you have the proper shop skills this is the bed for you.

King Size Murphy Bed Frame
Excellent. All parts are well made. The pages of direction cover everything we needed for installation. The spring system works great; we used all nine springs per side for a mattress that weighed in at about 180 lbs. Would highly recommend this for anyone. The level needed for installation is above a DIY level in my opinion.
